基于aws和hexo的静态blog

目录

1. 1. 基本的aws账号的set up
2. 2. 创建基础的pipeline
   1. 2.1. 整个pipeline看起来如下图所示：
   2. 2.2. 对应的cloudformation如下：
   3. 2.3. pipeline解释
3. 3. 域名、certificate
4. 4. static assets package
5. 5. cloudformation package

基本的aws账号的set up

• 申请AWS帐号，用邮箱和信用卡。这个申请的是root帐号。

• 为root帐号申请软件mfa，我用的是iphone上装的google authenticator。以后登录的时候用两步验证。

• (option)看一下iam user的最佳实践

• 创建一个admin user，也enable mfa，给全部权限:

  { "Version": "2012-10-17", "Statement": { "Effect": "Allow", "Action": "iam:*", "Resource": "*" } }

• root和admin只用aws console登录。

• 创建一个developer user，给予power user access权限，并且enable access key，以后本地开发，比如用aws cli，就用这个aws access key。

• 加一个policy，强制定期更新密码。

创建基础的pipeline

整个pipeline看起来如下图所示：

对应的cloudformation如下：

show code

AWSTemplateFormatVersion: "2010-09-09"

Description: >
  Used to create Pipeline.
  CodeCommit => CodeBuild => S3 => Cloudformation

Parameters:
  AppName:
    Description: Name of the pipeline
    Type: String
    Default: HexoBlog
  PipelineName:
    Description: Name of the pipeline
    Type: String
    Default: HexoBlogPipeline
  ArtifactS3BucketName:
    Description: Name of the s3 buckt to store artifacts
    Type: String
    Default: blog-pipeline-artifacts
  RepositoryBaseName:
    Description: Base name of the git repository
    Type: String
    Default: HexoBlog
  RepositoryBranchName:
    Description: CodeCommit branch name
    Type: String
    Default: master
  SNSSubscriptionEmail:
    Description: The email address to recieve notification
    Type: String
    Default: "***@qq.com" # your email

Resources:
  ######################################################################################################################
  # The S3 bucket to store artifacts
  ######################################################################################################################
  ArtifactStoreBucket:
    DeletionPolicy: Retain    # keeps everything after s3 bucket is deleted
    Type: AWS::S3::Bucket
    Properties:
      BucketName: {Ref: ArtifactS3BucketName}

  CodePipelineSNSTopic:
    Type: AWS::SNS::Topic
    Properties:
      Subscription:
        - Endpoint: {Ref: SNSSubscriptionEmail}
          Protocol: email-json

  AssetsCodeRepository:
    Type: AWS::CodeCommit::Repository
    Properties:
      RepositoryName:
        Fn::Sub: "${RepositoryBaseName}Assets"
      RepositoryDescription: >
        This repository contains the hexo assets

  CloudformationTemplatesCodeRepository:
    Type: AWS::CodeCommit::Repository
    Properties:
      RepositoryName:
        Fn::Sub: "${RepositoryBaseName}CloudformationTemplates"
      RepositoryDescription: >
        This repository contains the cloudformation templates to set up cloudfront.
  AmazonCloudWatchEventRule:
    DependsOn:
      - AssetsCodeRepository
      - CloudformationTemplatesCodeRepository
    Type: 'AWS::Events::Rule'
    Properties:
      EventPattern:
        source:
          - aws.codecommit
        detail-type:
          - CodeCommit Repository State Change
        resources:
          - Fn::Join:
            - ''
            - - 'arn:aws:codecommit:'
              - {Ref: 'AWS::Region'}
              - ':'
              - {Ref: 'AWS::AccountId'}
              - ':'
              - {"Fn::GetAtt" : ["AssetsCodeRepository", "Name"]}
          - Fn::Join:
            - ''
            - - 'arn:aws:codecommit:'
              - {Ref: 'AWS::Region'}
              - ':'
              - {Ref: 'AWS::AccountId'}
              - ':'
              - {"Fn::GetAtt" : ["CloudformationTemplatesCodeRepository", "Name"]}
        detail:
          event:
            - referenceCreated
            - referenceUpdated
          referenceType:
            - branch
          referenceName:
            - master
      Targets:
        - Arn:
            Fn::Join:
              - ''
              - - 'arn:aws:codepipeline:'
                - {Ref: 'AWS::Region'}
                - ':'
                - {Ref: 'AWS::AccountId'}
                - ':'
                - {Ref: Pipeline}
          RoleArn: {"Fn::GetAtt" : ["AmazonCloudWatchEventRole", "Arn"]}
          Id: codepipeline-Pipeline-autobuild
  ######################################################################################################################
  # The CodeBuild projects to build two packages
  ######################################################################################################################
  CloudformationTemplatesCodeBuildProject:
    Properties:
      Description: |
        This code build project is used to build cloudformation templates
      Artifacts:
        Type: CODEPIPELINE
      Environment:
        ComputeType: BUILD_GENERAL1_SMALL
        # EnvironmentVariables:
        #   - Name: BUILD_OUTPUT_BUCKET
        #     Value: BuildArtifactsBucket
        Image: "aws/codebuild/standard:2.0"
        Type: LINUX_CONTAINER
      Name:
        Fn::Sub: "${AppName}_cloudformation_templates_build"
      ServiceRole: {"Fn::GetAtt" : ["CodeBuildServiceRole", "Arn"]}
      Source:
        Type: CODEPIPELINE
    Type: "AWS::CodeBuild::Project"
  AssetsCodeBuildProject:
    Properties:
      Description: |
        This code build project is used to build hexo static assets
      Artifacts:
        Type: CODEPIPELINE
      Environment:
        ComputeType: BUILD_GENERAL1_SMALL
        # EnvironmentVariables:
        #   - Name: BUILD_OUTPUT_BUCKET
        #     Value: BuildArtifactsBucket
        Image: "aws/codebuild/standard:2.0"
        Type: LINUX_CONTAINER
      Name:
        Fn::Sub: "${AppName}_assets_build"
      ServiceRole: {"Fn::GetAtt": ["CodeBuildServiceRole", "Arn"] }
      Source:
        Type: CODEPIPELINE
    Type: "AWS::CodeBuild::Project"

  ######################################################################################################################
  # The real pipeline definition
  ######################################################################################################################
  Pipeline:
    Type: AWS::CodePipeline::Pipeline
    Properties:
      ArtifactStore:
        Location: {Ref: ArtifactStoreBucket}
        Type: S3
      DisableInboundStageTransitions: []
      Name: {Ref: PipelineName}
      RoleArn: {"Fn::GetAtt" : ["CodePipelineExecutionRole", "Arn"]}
      Stages:
        - Name: CodeCommitSource
          Actions:
            - Name: CloudformationTemplatesCodeRepository
              ActionTypeId:
                Category: Source
                Owner: AWS
                Provider: CodeCommit
                Version: 1
              Configuration:
                BranchName: {Ref: RepositoryBranchName}
                RepositoryName: {'Fn::GetAtt': [CloudformationTemplatesCodeRepository, Name]}
                PollForSourceChanges: false # see https://docs.aws.amazon.com/codepipeline/latest/userguide/run-automatically-polling.html
                                            # we use cloudwatch event to trigger pipeline other than let it poll
              OutputArtifacts:
                - Name: CloudformationTemplatesSourceArtifacts
            - Name: AssetsCodeRepository
              ActionTypeId:
                Category: Source
                Owner: AWS
                Provider: CodeCommit
                Version: 1
              Configuration:
                BranchName: {Ref: RepositoryBranchName}
                RepositoryName: {'Fn::GetAtt': [AssetsCodeRepository, Name]}
                PollForSourceChanges: false # see https://docs.aws.amazon.com/codepipeline/latest/userguide/run-automatically-polling.html
                                            # we use cloudwatch event to trigger pipeline other than let it poll
              OutputArtifacts:
                - Name: AssetsSourceArtifacts
        - Name: Build
          Actions:
            - Name: BuildAssets
              ActionTypeId:
                Category: Build
                Owner: AWS
                Provider: CodeBuild
                Version: 1
              InputArtifacts:
                - Name: AssetsSourceArtifacts
              OutputArtifacts:
                - Name: AssetsBuildArtifacts
              Configuration:
                ProjectName: {Ref: AssetsCodeBuildProject}
              RunOrder: 1 # The assets package depend on nothing, so build it first.
            - Name: BuildCloudformationTemplate
              ActionTypeId:
                Category: Build
                Owner: AWS
                Provider: CodeBuild
                Version: 1
              InputArtifacts:
                - Name: CloudformationTemplatesSourceArtifacts
              OutputArtifacts:
                - Name: CloudformationTemplatesBuildArtifacts
              Configuration:
                ProjectName: {Ref: CloudformationTemplatesCodeBuildProject}
              RunOrder: 1
        - Name: Beta
          Actions:
            - Name: CreateBetaChangeSet
              ActionTypeId:
                Category: Deploy
                Owner: AWS
                Provider: CloudFormation
                Version: 1
              Configuration:
                ActionMode: CHANGE_SET_REPLACE
                Capabilities: CAPABILITY_IAM
                ChangeSetName:
                  Fn::Sub: "${AppName}-ChangeSet-Beta"
                ParameterOverrides: |
                  {
                    "SourceBucket": {
                      "Fn::GetArtifactAtt": ["CloudformationTemplatesBuildArtifacts", "BucketName"]
                    },
                    "SourceArtifactKey": {
                      "Fn::GetArtifactAtt": ["CloudformationTemplatesBuildArtifacts", "ObjectKey"]
                    },
                    "AssetsSourceBucket": {
                      "Fn::GetArtifactAtt": ["AssetsBuildArtifacts", "BucketName"]
                    },
                    "AssetsSourceArtifactKey": {
                      "Fn::GetArtifactAtt": ["AssetsBuildArtifacts", "ObjectKey"]
                    },
                    "Stage": "beta",
                    "ExportBetaForTest": "true"
                  }
                RoleArn: {"Fn::GetAtt" : ["CloudFormationExecutionRole", "Arn"]}
                StackName:
                  Fn::Sub: "${AppName}-Stack-Beta"
                TemplatePath: "CloudformationTemplatesBuildArtifacts::cloudformation.yaml"
              InputArtifacts:
                - Name: CloudformationTemplatesBuildArtifacts
                - Name: AssetsBuildArtifacts
              RunOrder: 1
            - Name: ExecuteBetaChangeSet
              ActionTypeId:
                Category: Deploy
                Owner: AWS
                Provider: CloudFormation
                Version: 1
              Configuration:
                ActionMode: CHANGE_SET_EXECUTE
                ChangeSetName:
                  Fn::Sub: "${AppName}-ChangeSet-Beta"
                RoleArn: {"Fn::GetAtt" : ["CloudFormationExecutionRole", "Arn"]}
                StackName:
                  Fn::Sub: "${AppName}-Stack-Beta"
              OutputArtifacts:
                - Name:
                    Fn::Sub: "${AppName}BetaChangeSet"
              RunOrder: 2
        - Name: Prod
          Actions:
            - Name: DeploymentApproval
              ActionTypeId:
                Category: Approval
                Owner: AWS
                Provider: Manual
                Version: 1
              Configuration:
                NotificationArn: {Ref: CodePipelineSNSTopic}
                CustomData: |
                  Do you want to update the prod stack?
              RunOrder: 1
            - Name: BlockBetaPortal
              ActionTypeId:
                Category: Deploy
                Owner: AWS
                Provider: CloudFormation
                Version: '1'
              Configuration:
                ActionMode: CREATE_UPDATE
                Capabilities: CAPABILITY_IAM
                RoleArn: {"Fn::GetAtt" : ["CloudFormationExecutionRole", "Arn"]}
                ParameterOverrides: |
                  {
                    "SourceBucket": {
                      "Fn::GetArtifactAtt": ["CloudformationTemplatesBuildArtifacts", "BucketName"]
                    },
                    "SourceArtifactKey": {
                      "Fn::GetArtifactAtt": ["CloudformationTemplatesBuildArtifacts", "ObjectKey"]
                    },
                    "AssetsSourceBucket": {
                      "Fn::GetArtifactAtt": ["AssetsBuildArtifacts", "BucketName"]
                    },
                    "AssetsSourceArtifactKey": {
                      "Fn::GetArtifactAtt": ["AssetsBuildArtifacts", "ObjectKey"]
                    },
                    "Stage": "beta",
                    "ExportBetaForTest": "false"
                  }
                StackName:
                  Fn::Sub: "${AppName}-Stack-Beta"
                TemplatePath: "CloudformationTemplatesBuildArtifacts::cloudformation.yaml"
              InputArtifacts:
                - Name: CloudformationTemplatesBuildArtifacts
                - Name: AssetsBuildArtifacts
              RunOrder: 2
            - Name: DeployToProd
              ActionTypeId:
                Category: Deploy
                Owner: AWS
                Provider: CloudFormation
                Version: 1
              Configuration:
                ActionMode: CREATE_UPDATE
                Capabilities: CAPABILITY_IAM
                RoleArn: {"Fn::GetAtt": ["CloudFormationExecutionRole", "Arn"]}
                ParameterOverrides: >
                  {
                    "SourceBucket": {
                      "Fn::GetArtifactAtt": ["CloudformationTemplatesBuildArtifacts", "BucketName"]
                    },
                    "SourceArtifactKey": {
                      "Fn::GetArtifactAtt": ["CloudformationTemplatesBuildArtifacts", "ObjectKey"]
                    },
                    "AssetsSourceBucket": {
                      "Fn::GetArtifactAtt": ["AssetsBuildArtifacts", "BucketName"]
                    },
                    "AssetsSourceArtifactKey": {
                      "Fn::GetArtifactAtt": ["AssetsBuildArtifacts", "ObjectKey"]
                    },
                    "Stage": "prod",
                    "ExportBetaForTest": "true"
                  }
                StackName:
                  Fn::Sub: "${AppName}-Stack-Prod"
                TemplatePath: "CloudformationTemplatesBuildArtifacts::cloudformation.yaml"
              InputArtifacts:
                - Name: CloudformationTemplatesBuildArtifacts
                - Name: AssetsBuildArtifacts
              OutputArtifacts:
                - Name:
                    Fn::Sub: "${AppName}ProdChangeSet"
              RunOrder: 3


  ######################################################################################################################
  # IAM Policies & Roles
  ######################################################################################################################
  CodeBuildServiceRole:
    Type: "AWS::IAM::Role"
    Properties:
      AssumeRolePolicyDocument:
        Statement:
          - Action:
              - "sts:AssumeRole"
            Effect: Allow
            Principal:
              Service:
                - codebuild.amazonaws.com
        Version: "2012-10-17"
      Path: /
      Policies:
        - PolicyDocument:
            Statement:
              - Sid: CloudWatchLogsPolicy
                Action:
                  - "logs:CreateLogGroup"
                  - "logs:CreateLogStream"
                  - "logs:PutLogEvents"
                Effect: Allow
                Resource:
                  - Fn::Sub: "arn:aws:logs:${AWS::Region}:${AWS::AccountId}:log-group:/aws/codebuild/*"
              - Sid: CodeCommitPolicy
                Action:
                  - "codecommit:GitPull"
                Effect: Allow
                Resource: "*"
              - Sid: S3GetObjectPolicy
                Action:
                  - "s3:GetObject"
                  - "s3:GetObjectVersion"
                Effect: Allow
                Resource:
                  - Fn::Sub: "arn:aws:s3:::${ArtifactStoreBucket}/*"
              - Sid: S3PutObjectPolicy
                Action:
                  - "s3:PutObject"
                Effect: Allow
                Resource:
                  - Fn::Sub: "arn:aws:s3:::${ArtifactStoreBucket}/*"
              - Action:
                  - "cloudformation:DescribeStacks"
                Effect: Allow
                Resource: "*"
            Version: "2012-10-17"
          PolicyName: CodeBuildAccess
  CodePipelineExecutionRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Statement:
          - Action:
              - "sts:AssumeRole"
            Effect: Allow
            Principal:
              Service:
                - codepipeline.amazonaws.com
        Version: "2012-10-17"
      Path: /
      ManagedPolicyArns:
        - "arn:aws:iam::aws:policy/AWSCodeCommitFullAccess"
        - "arn:aws:iam::aws:policy/AWSCodeDeployFullAccess"
        - "arn:aws:iam::aws:policy/AmazonS3FullAccess"
        - "arn:aws:iam::aws:policy/AmazonEC2FullAccess"
        - "arn:aws:iam::aws:policy/AmazonSNSFullAccess"
        - "arn:aws:iam::aws:policy/AmazonSQSFullAccess"
        - "arn:aws:iam::aws:policy/AmazonECS_FullAccess"
        - "arn:aws:iam::aws:policy/AWSOpsWorksFullAccess"
        - "arn:aws:iam::aws:policy/AWSCodeBuildAdminAccess"
      Policies:
        -
          PolicyDocument:
            Statement:
              -
                Action:
                  - "iam:PassRole"
                  - "elasticbeanstalk:*"
                  - "cloudformation:*"
                  - "ecr:DescribeImages"
                  - "lambda:InvokeFunction"
                  - "lambda:ListFunctions"
                  - "lambda:InvokeAsyc"
                Effect: Allow
                Resource: "*"
            Version: "2012-10-17"
          PolicyName: CodePipelineInlinePolicy
  CloudFormationExecutionRole:
    Properties:
      AssumeRolePolicyDocument:
        Statement:
          Action:
            - "sts:AssumeRole"
          Effect: Allow
          Principal:
            Service:
              - cloudformation.amazonaws.com
        Version: "2012-10-17"
      ManagedPolicyArns:
        - "arn:aws:iam::aws:policy/AdministratorAccess"
      Path: /
    Type: "AWS::IAM::Role"
  AmazonCloudWatchEventRole:
    Type: 'AWS::IAM::Role'
    Properties:
      AssumeRolePolicyDocument:
        Version: 2012-10-17
        Statement:
          - Effect: Allow
            Principal:
              Service:
                - events.amazonaws.com
            Action: 'sts:AssumeRole'
      Path: /
      Policies:
        - PolicyName: cwe-pipeline-execution
          PolicyDocument:
            Version: 2012-10-17
            Statement:
              - Effect: Allow
                Action: 'codepipeline:StartPipelineExecution'
                Resource:
                  Fn::Join:
                    - ''
                    - - 'arn:aws:codepipeline:'
                      - {Ref: 'AWS::Region'}
                      - ':'
                      - {Ref: 'AWS::AccountId'}
                      - ':'
                      - {Ref: 'Pipeline'}

pipeline解释

• 有两个package，一个是用来生成static assets(html, js等)的，另一个是负责创建cloudfront相关的cloudformation templates。
• 这两个package用code build构建之后，先部署到beta的cloudformation stack，然后人工approve后部署到prod的cloudformation stack。

域名、certificate

• 我想用自己的域名，于是去route53申请了一个。申请之后会自动创建一个hosted zone，在里面可以创建record把子域名绑定到prod的cloudfront上。
• 为了用https，需要去ACM里申请一个certificate

static assets package

• 我用的hexo来创建静态的blog页面。对应的buildsspec文件如下:

show code

version: 0.2
phases:
  install:
    runtime-versions:
      nodejs: 10
    commands:
      - echo installing dependencies...
      - npm install -g hexo-cli
      - npm install
      - echo finished installing dependencies!
  # pre_build: use this phase to run tests
  build:
    commands:
      - echo generating static assets...
      - hexo generate
      - echo finished generating static assets!
  post_build:
    commands:
      - echo copying favicon.png...
      - cp favicon.png public/favicon.png
      - echo finished copying favicon.png!
artifacts:
  files:
    - '**/*'
  base-directory: public

• hexo默认的theme，用了一些google的字体、jquery cdn等。众所周知，需要替换。把themes/landscape/layout/_partial下面的文件，一个是after-footer.ejs，一个是head.ejs，里面的google url自己找国内对应的替换。
• cloudfront不能把指向sub dir的url自动重定向到sub dir下面的index.html，所以要在生成静态文件的时候一步到位。加一个script(/home/xiaoma/WebstormProjects/HexoBlogAssets/themes/landscape/scripts/url_for.js)来替换默认的url_for:

show code

      const _path = require('path');
const origin_url_for = hexo.extend.helper.get('url_for').bind(hexo);

hexo.extend.helper.register('url_for', function(path, options) {
    origin_url = origin_url_for(path, options);
    console.log(origin_url);
    if (_path.extname(origin_url)) {
        return origin_url;
    } else {
        return _path.join(origin_url, 'index.html')
    }
});

cloudformation package

• 这个package包含了cloudformation template和aws lambda用到的python代码。buildspec如下：

show code

version: 0.2
phases:
  install:
    runtime-versions:
      python: 3.7
    commands:
      - echo installing dependencies...
      - mkdir artifacts
      - pip install -r requirements.txt -t artifacts
      - echo finished installing dependencies!
  # pre_build: use this phase to run tests
  build:
    commands:
      - echo packaging lambda...
      - cp HexoBlogCloudFormationTemplates/lambda_handler.py artifacts/lambda_handler.py
      - echo finished packaging lambda!
  post_build:
    commands:
      - echo copying cloudformation templates...
      - cp HexoBlogCloudFormationTemplates/configuration/cloudformation/blog.yaml artifacts/cloudformation.yaml
      - echo finished preparing artifacts!
artifacts:
  files:
    - '**/*'
  base-directory: artifacts

• cloudformation包括了将static assets从code build的output复制到cloudfront bucket的lambda和cloudfront的配置。其中，当stage是prod的时候，cloudfront要绑定域名。

show code

AWSTemplateFormatVersion: "2010-09-09"

Description: >
  Create Cloudfront distribution for static assets in s3


Parameters:
  SourceBucket:             # s3 bucket of this package after build
    Type: String
  SourceArtifactKey:        # s3 key of this package after build
    Type: String
  AssetsSourceBucket:       # s3 bucket of assets after build
    Type: String
  AssetsSourceArtifactKey:  # s3 key of assets after build
    Type: String
  Stage:
    Type: String
    Default: beta
    AllowedValues: ["beta", "prod"]
  ExportBetaForTest:
    Type: String
    AllowedValues: ["true", "false"]
  DomainNames:
    Type: CommaDelimitedList
    Default: 'blog.02xiaoma.com, www.02xiaoma.com, www.blog.02xiaoma.com, 02xiaoma.com'
  CertificateArn:
    Type: String
    Default: '' #arn of your acm certificate

Conditions:
  ProdStage:
    Fn::Equals :
      - {"Ref" : "Stage"}
      - prod

Outputs:
  CloudfrontDomainName:
    Value: {'Fn::GetAtt': [CloudFrontDistribution, DomainName]}


Resources:
  ######################################################################################################################
  # The S3 bucket to store artifacts
  ######################################################################################################################
  CloudfrontBucket:
    Type: AWS::S3::Bucket

  CloudfrontBucketPolicy:
    Type: AWS::S3::BucketPolicy
    Properties:
      Bucket: {Ref: CloudfrontBucket}
      PolicyDocument:
        Statement:
          - Action: ['s3:GetObject']
            Effect: Allow
            Principal:
              CanonicalUser:
                Fn::GetAtt: [Cloudfrontoriginaccessidentity, S3CanonicalUserId]
            Resource: {'Fn::Sub': 'arn:aws:s3:::${CloudfrontBucket}/*'}
          - Action: ['s3:ListBucket']
            Effect: Allow
            Principal:
              CanonicalUser:
                Fn::GetAtt: [Cloudfrontoriginaccessidentity, S3CanonicalUserId]
            Resource: {'Fn::Sub': 'arn:aws:s3:::${CloudfrontBucket}'}
          - Action: ['s3:*']
            Effect: Allow
            Principal:
              AWS: {'Fn::Sub': 'arn:aws:iam::${AWS::AccountId}:root'}
            Resource: {'Fn::Sub': 'arn:aws:s3:::${CloudfrontBucket}/*'}

  ######################################################################################################################
  # Custom resources to copy artifacts and invalidate cloud front distribution
  ######################################################################################################################
  AssetsCopyLambda:
    DependsOn:
      - AssetsCopyLambdaRole
    Type: AWS::Lambda::Function
    Properties:
      Description: copy assets into cloudfront bucket
      Runtime: python3.7
      Handler: lambda_handler.assets_copy_handler
      MemorySize: 256
      Timeout: 300
      Code:
        S3Bucket: {Ref: SourceBucket}
        S3Key: {Ref: SourceArtifactKey}
      Role:
        Fn::GetAtt: [AssetsCopyLambdaRole, Arn]
  AssetsCopyLambdaRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
          - Action: ['sts:AssumeRole']
            Effect: Allow
            Principal:
              Service: [lambda.amazonaws.com]
      ManagedPolicyArns: ['arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole']
      Policies:
        - PolicyName: AssetsCopyLambdaPolicy
          PolicyDocument:
            Statement:
              - Action:
                  - s3:*
                  - kms:*
                Effect: Allow
                Resource: '*'
  AssetsCopyLambdaCustomResource:
    Type: AWS::CloudFormation::CustomResource
    DependsOn:
      - AssetsCopyLambda
      - CloudfrontBucket
      - CloudfrontBucketPolicy
    Properties:
      DstBucket: {Ref: CloudfrontBucket}
      SrcBucket: {Ref: AssetsSourceBucket}
      SrcObjectKey: {Ref: AssetsSourceArtifactKey} # force run when static assets changed
      ServiceToken:
        Fn::GetAtt: [AssetsCopyLambda, Arn]

  CloudfrontInvalidateLambda:
    DependsOn:
      - CloudfrontInvalidateLambdaRole
    Type: AWS::Lambda::Function
    Properties:
      Description: Invalidate a cloudformation distribution
      Runtime: python3.7
      Handler: lambda_handler.cloudfront_invalidate_handler
      MemorySize: 256
      Timeout: 300
      Code:
        S3Bucket: {Ref: SourceBucket}
        S3Key: {Ref: SourceArtifactKey}
      Role:
        Fn::GetAtt: [CloudfrontInvalidateLambdaRole, Arn]
  CloudfrontInvalidateLambdaRole:
    Type: AWS::IAM::Role
    Properties:
      AssumeRolePolicyDocument:
        Version: '2012-10-17'
        Statement:
          - Action: ['sts:AssumeRole']
            Effect: Allow
            Principal:
              Service: [lambda.amazonaws.com]
      ManagedPolicyArns: ['arn:aws:iam::aws:policy/service-role/AWSLambdaBasicExecutionRole']
      Policies:
        - PolicyName: CloudfrontInvalidateLambdaPolicy
          PolicyDocument:
            Statement:
              - Action: ['cloudfront:CreateInvalidation']
                Effect: Allow
                Resource: '*'
  CloudfrontInvalidateCustomResource:
    Type: AWS::CloudFormation::CustomResource
    DependsOn:
      - CloudfrontInvalidateLambda
    Properties:
      OriginAssets: # force run when cloudfront origin path changed
        Fn::GetAtt: [AssetsCopyLambdaCustomResource, OriginPath]
      DistributionId: {Ref: CloudFrontDistribution}
      ServiceToken:
        Fn::GetAtt: [CloudfrontInvalidateLambda, Arn]


  ######################################################################################################################
  # Cloudfront distribution
  ######################################################################################################################
  CloudFrontDistribution:
    DependsOn:
      - CloudfrontBucket
    Type: AWS::CloudFront::Distribution
    Properties:
      DistributionConfig:
        Aliases:
          Fn::If:
            - ProdStage
            - {Ref: DomainNames}
            - {Ref: 'AWS::NoValue'}
        DefaultCacheBehavior:
          AllowedMethods: [GET, HEAD, OPTIONS]
          Compress: true
          ForwardedValues:
            Cookies: {Forward: none}
            QueryString: 'false'
          TargetOriginId: hexo_blog_static_assets
          ViewerProtocolPolicy: redirect-to-https
        DefaultRootObject: index.html
        Enabled: true
        HttpVersion: http2
        Origins:
          - DomainName:
              Fn::GetAtt: [CloudfrontBucket, RegionalDomainName]
            Id: hexo_blog_static_assets
            OriginPath:
              Fn::GetAtt: [AssetsCopyLambdaCustomResource, OriginPath]
            S3OriginConfig:
              OriginAccessIdentity:
                Fn::Sub:
                  - origin-access-identity/cloudfront/${Id}
                  - Id: {Ref: Cloudfrontoriginaccessidentity}
        PriceClass: PriceClass_200
        ViewerCertificate:
          AcmCertificateArn:
            Fn::If:
              - ProdStage
              - {Ref: CertificateArn}
              - {Ref: 'AWS::NoValue'}
          CloudFrontDefaultCertificate:
            Fn::If:
              - ProdStage
              - {Ref: 'AWS::NoValue'}
              - true
          SslSupportMethod:
            Fn::If:
              - ProdStage
              - sni-only
              - {Ref: 'AWS::NoValue'}

  Cloudfrontoriginaccessidentity:
    Type: AWS::CloudFront::CloudFrontOriginAccessIdentity
    Properties:
      CloudFrontOriginAccessIdentityConfig:
        Comment: string-value

• 用到的lambda code:

show code

from __future__ import print_function
import logging
import json
import uuid
import boto3
from botocore.client import Config
import requests
import time
import datetime
import zipfile
import mimetypes
from io import BytesIO

logger = logging.getLogger()
logger.setLevel(logging.INFO)
SUCCESS = 'SUCCESS'
FAILED = 'FAILED'


def custom_handler_decorator(func):
    def __decorator(event, context):
        logger.info(json.dumps(event))
        response = {
            'StackId': event['StackId'],
            'RequestId': event['RequestId'],
            'LogicalResourceId': event['LogicalResourceId'],
            'Status': 'SUCCESS',
            'Data': {}
        }

        if 'PhysicalResourceId' in event:
            response['PhysicalResourceId'] = event['PhysicalResourceId']
        else:
            response['PhysicalResourceId'] = event['PhysicalResourceId'] = str(uuid.uuid4())

        try:
            response.update(func(event, context))
        except Exception as e:
            logger.error(e)
            response['Status'] = 'FAILED'
            response['Reason'] = 'Failed to run handler'

        return send_response(event, response)
    return __decorator


def send_response(event, response):
    logger.info("sending response to cloudformation...")
    logger.info(json.dumps(response))
    if 'ResponseURL' in event and event['ResponseURL']:
        body = json.dumps(response)
        try:
            headers = {'Content-Type': ''}
            r = requests.put(event['ResponseURL'], data=body, headers=headers)
            r.raise_for_status()
            logger.info("finished sending response to clouformation")
        except requests.exceptions.HTTPError as e:
            logger.error("send response to CloudFormation failed with status %d" % e.response.status_code)
            logger.error("response: %s" % e.response.text)
        except requests.exceptions.RequestException as e:
            logger.error("failed to reach CloudFormation: %s" % e)
    else:
        logger.error("missing ResponseURL in event")
        raise ValueError("missing ResponseURL in event")


@custom_handler_decorator
def assets_copy_handler(event, context):
    request_type = event['RequestType']
    if request_type in ['Create', 'Update']:
        mimetypes.init()
        logger.info("copying static assets...")
        s3_client = boto3.client('s3', config=Config(signature_version='s3v4'))
        properties = event['ResourceProperties']
        dst_bucket = properties['DstBucket']
        src_bucket = properties['SrcBucket']
        src_objectkey = properties['SrcObjectKey']
        dst_objectpath = "{0}-{1}".format(datetime.datetime.utcnow().strftime('%Y-%m-%d-%H-%I-%M-%S'), str(uuid.uuid4()))
        s3_client
        logger.info("extracting static assets from s3://{0}/{1} to s3://{2}/{3}".format(src_bucket, src_objectkey, dst_bucket, dst_objectpath))
        with zipfile.ZipFile(
                BytesIO(
                    s3_client.get_object(Bucket=src_bucket, Key=src_objectkey)['Body'].read()
                )
        ) as zipdir:
            for filename in zipdir.namelist():
                logger.info("copying {0} to s3://{1}/{2}/{0}".format(filename, dst_bucket, dst_objectpath))
                mime_type = mimetypes.guess_type(filename)[0]
                if mime_type is None:
                    if filename.endswith('.wasm'):
                        mime_type = 'application/wasm'
                    else:
                        mime_type = 'application/octet-stream'
                if mime_type == 'text/html':
                    mime_type = 'text/html; charset=utf-8'
                logger.info("guessed mime type of {0} is {1}".format(filename, mime_type))
                extra_args = {
                    'ContentType': mime_type,
                    'CacheControl': 'max-age=31536000'
                }
                with zipdir.open(filename, 'r') as fp:
                    s3_client.upload_fileobj(fp, dst_bucket, "{0}/{1}".format(dst_objectpath, filename), extra_args)
        return {'Data': {'OriginPath': "/{0}".format(dst_objectpath)}}
    else:
        return {}


@custom_handler_decorator
def cloudfront_invalidate_handler(event, context):
    logger.info("invalidating cloudfront distribution...")
    cloufront_client = boto3.client('cloudfront')
    properties = event['ResourceProperties']
    dist_id = properties['DistributionId']
    object_paths = '/*'.split()
    cloufront_client.create_invalidation(
        DistributionId=dist_id,
        InvalidationBatch={
            'Paths': {
                'Quantity': len(object_paths),
                'Items': object_paths
            },
            'CallerReference': str(time.time())
        }
    )
    return {}
